Actual signals and parameters 221
3604
START DAY 1
1…7 1 1
Defines the weekly start day.
1 = MONDAY…7 = SUNDAY.
• If parameter value is 1, then period 1 weekly is active from Monday midnight
(00:00:00).
3605
STOP DAY 1
1…7 1 1
Defines weekly stop day.
1 = MONDAY…7 = SUNDAY.
• If parameter value is 5, then timer 1 weekly will be deactivated on Friday midnight
(23:59:58).
3606
START TIME 2
00:00:00 … 23:59:58 2 s 12:00:00
Defines timer 2 daily start time.
• See parameter 3602 START TIME 1.
3607
STOP TIME 2
00:00:00 … 23:59:58 2 s 12:00:00
Defines timer 2 daily stop time.
• See parameter 3603 STOP TIME 1.
3608
START DAY 2
1…7 1 1
Defines timer 2 weekly start day.
• See parameter 3604 START DAY 1.
3609
STOP DAY 2
1…7 1 1
Defines timer 2 weekly stop day.
• See parameter 3605 STOP DAY 1.
3610
START TIME 3
00:00:00 … 23:59:58 2 s 12:00:00
Defines timer 3 daily start time.
• See parameter 3602 START TIME 1.
3611
STOP TIME 3
00:00:00 … 23:59:58 2 s 12:00:00
Defines timer 3 daily stop time.
• See parameter 3603 STOP TIME 1.
3612
START DAY 3
1…7 1 1
Defines timer 3 weekly start day.
• See parameter 3604 START DAY 1.
3613
STOP DAY 3
1…7 1 1
Defines timer 3 weekly stop day.
• See parameter 3605 STOP DAY 1.
3614
START TIME 4
00:00:00 … 23:59:58 2 s 12:00:00
Defines timer 4 daily start time.
• See parameter 3602 START TIME 1.
3615
STOP TIME 4
00:00:00 … 23:59:58 2 s 12:00:00
Defines timer 4 daily stop time.
• See parameter 3603 STOP TIME 1.
Group 36: Timed functions
Code Description Range Resolution Default S
