176 Parameters
06.18 Start inhibit status
word
Start inhibit status word. This word specifies the source of the
inhibiting signal that is preventing the drive from starting.
The conditions marked with an asterisk (*) only require that
the start command is cycled. In all other instances, the
inhibiting condition must be removed first.
See also parameter 06.16 Drive status word 1, bit 1.
This parameter is read-only.
0b0000
0b0000...0b1111 Sta rt inhibit status word. 1 = 1
06.19 Speed control
status word
Speed control status word.
This parameter is read-only.
0b0000
0b0000...0b1111 Spe ed control status word. 1 = 1
No. Name/Value Description Def/FbEq16
Bit Name Description
0 Not ready run 1 = DC voltage is missing or drive has not been parametrized
correctly. Check the parameters in groups 95 and 99.
1 Ctrl location changed * 1 = Control location has changed.
2 SSW inhibit 1 = Control program is keeping itself in inhibited state.
3 Fault reset * 1 = A fault has been reset.
4 Lost start enable 1 = Start enable signal missing.
5 Lost run enable 1 = Run enable signal missing.
6 Reserved
7 STO 1 = Safe torque off function active.
8 Current calibration
ended
* 1 = Current calibration routine has finished.
9 ID run ended * 1 = Motor identification run has finished.
10 Reserved
11 Em Off1 1 = Emergency stop signal (mode off1).
12 Em Off2 1 = Emergency stop signal (mode off2).
13 Em Off3 1 = Emergency stop signal (mode off3).
14 Auto reset inhibit 1 = The autoreset function is inhibiting operation.
15 Jogging active 1 = The jogging enable signal is inhibiting operation.
Bit Name Description
0 Zero speed
1 = Drive has been running below zero speed limit (par. 21.06)
for a time defined by parameter 21.07 Zero speed delay.
1Forward
1 = Drive is running in forward direction above zero speed limit
(par. 21.06).
2 Reverse
1 = Drive is running in reverse direction above zero speed limit
(par. 21.06).
3…6 Reserved
7
Any constant speed
request
1 = A constant speed or frequency has been selected; see par.
06.20.
8…15 Reserved
