Parameters 177
06.20 Constant speed
status word
Constant speed/frequency status word. Indicates which
constant speed or frequency is active (if any). See also
parameter 06.19 Speed control status word, bit 7, and section
Constant speeds/frequencies (page 44).
This parameter is read-only.
0b0000
0b0000...0b1111 Constant speed/frequency status word. 1 = 1
06.21 Drive status word 3 Drive status word 3.
This parameter is read-only.
0b0000
0b0000...0b1111 Drive stat us wo rd 1. 1 = 1
06.29 MSW bit 10
selection
Selects a binary source whose status is transmitted as bit 10
(User bit 0) of 06.11 Main status word.
Above limit
False 0 0
True 1 1
Above limit Bit 10 of 06.17 Drive status word 2 (see page 175). 2
Other [bit] Source selection (see Terms and abbreviations on page 162). -
06.30 MSW bit 11
selection
Selects a binary source whose status is transmitted as bit 11
(User bit 0) of 06.11 Main status word.
Ext ctrl loc
False 0 0
True 1 1
Ext ctrl loc Bit 11 of 06.01 Main control word (see page 174). 2
Other [bit] Source selection (see Terms and abbreviations on page 162). -
06.31 MSW bit 12
selection
Selects a binary source whose status is transmitted as bit 12
(User bit 1) of 06.11 Main status word.
Ext run
enable
False 0 0
True 1 1
Ext run enable Status of the external run enable signal (see parameter 20.12
Run enable 1 source)
2
Other [bit] Source selection (see Terms and abbreviations on page 162). -
No. Name/Value Description Def/FbEq16
Bit Name Description
0 Constant speed 1 1 = Constant speed or frequency 1 selected
1 Constant speed 2 1 = Constant speed or frequency 2 selected
2 Constant speed 3 1 = Constant speed or frequency 3 selected
3 Constant speed 4 1 = Constant speed or frequency 4 selected
4 Constant speed 5 1 = Constant speed or frequency 5 selected
5 Constant speed 6 1 = Constant speed or frequency 6 selected
6 Constant speed 7 1 = Constant speed or frequency 7 selected
7…15 Reserved
Bit Name Description
0 DC hold active 1 = DC hold is active.
1 Post-magnetizing
active
1 = Post-magnetizing is active.
2 Motor pre-heating
active
1 = Motor pre-heating is active.
3…15 Reserved
