206 Parameters
20.12 Run enable 1
source
Selects the source of the external run enable signal. If the run
enable signal is switched off, the drive will not start. If already
running, the drive will stop according to the setting of
parameter 20.11 Run enable stop mode.
1 = Run enable signal on.
See also parameter 20.19 Enable start command.
Selected
Not selected 0 0
Selected 1 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0) 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1) 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2) 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3) 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4) 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5) 7
Timed function 1 Bit 0 of 34.01 Timed functions status (see page 273)18
Timed function 2 Bit 1 of 34.01 Timed functions status (see page 273)19
Timed function 3 Bit 2 of 34.01 Timed functions status (see page 273)20
Supervision 1 Bit 0 of 32.01 Supervision status (see page 266)24
Supervision 2 Bit 1 of 32.01 Supervision status (see page 266)25
Supervision 3 Bit 2 of 32.01 Supervision status (see page 266)26
FBA A MCW bit 3 Control word bit 3 received through fieldbus interface A 30
EFB MCW bit 3 Control word bit 3 received through the embedded fieldbus
interface
32
Other [bit] Source selection (see Terms and abbreviations on page 162)-
20.19 Enable start
command
Selects the source for the start enable signal.
1 = Start enable.
With the signal switched off, any drive start command is
inhibited. (Switching the signal off while the drive is running
will not stop the drive.)
See also parameter 20.12 Run enable 1 source.
Selected
Not selected 0 0
Selected 1 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0) 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1) 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2) 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3) 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4) 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5) 7
Timed function 1 Bit 0 of 34.01 Timed functions status (see page 273)18
Timed function 2 Bit 1 of 34.01 Timed functions status (see page 273)19
Timed function 3 Bit 2 of 34.01 Timed functions status (see page 273)20
Supervision 1 Bit 0 of 32.01 Supervision status (see page 266)24
Supervision 2 Bit 1 of 32.01 Supervision status (see page 266)25
Supervision 3 Bit 2 of 32.01 Supervision status (see page 266)26
No. Name/Value Description Def/FbEq16
