Parameters 205
In1P Start fwd; In2P
Start rev; In3 Stop
The sources of the start and stop commands are selected by
parameters 20.08 Ext2 in1 source, 20.09 Ext2 in2 source and
20.10 Ext2 in3 source. The source selected by 20.10 Ext2 in3
source determines the direction. The state transitions of the
source bits are interpreted as follows:
Note: Parameter 20.07 Ext2 start trigger type has no effect
with this setting.
6
Control panel The start and stop commands are taken from the control
panel (or PC connected to the panel connector).
11
Fieldbus A The start and stop commands are taken from fieldbus adapter
A.
Note: Set also 20.07 Ext2 start trigger type to Level.
12
Embedded fieldbus The start and stop commands are taken from the embedded
fieldbus interface.
Note: Set also 20.07 Ext2 start trigger type to Level.
14
20.07 Ext2 start trigger
type
Defines whether the start signal for external control location
EXT2 is edge-triggered or level-triggered.
Note: This parameter is not effective if a pulse-type start
signal is selected. See the descriptions of the selections of
parameter 20.06 Ext2 commands.
Level
Edge The start signal is edge-triggered. 0
Level The start signal is level-triggered. 1
20.08 Ext2 in1 source Selects source 1 for parameter 20.06 Ext2 commands.
For the available selections, see parameter 20.03 Ext1 in1
source.
Always off
20.09 Ext2 in2 source Selects source 2 for parameter 20.06 Ext2 commands.
For the available selections, see parameter 20.03 Ext1 in1
source.
Always off
20.10 Ext2 in3 source Selects source 3 for parameter 20.06 Ext2 commands.
For the available selections, see parameter 20.03 Ext1 in1
source.
Always off
20.11 Run enable stop
mode
Selects the way the motor is stopped when the run enable
signal switches off.
The source of the run enable signal is selected by parameter
20.12 Run enable 1 source.
Coast
Coast Stops by switching off the output semiconductors of the drive.
The motor coasts to a stop.
WARNING! If a mechanical brake is used, ensure it is
safe to stop the drive by coasting.
0
Ramp Stops along the active deceleration ramp. See parameter
group 23 Speed reference ramp on page 226.
1
Torque limit Stops according to torque limits (parameters 30.19 and
30.20).
2
No. Name/Value Description Def/FbEq16
State of
source 1
(20.08)
State of
source 2
(20.09)
State of
source 3
(20.10)
Command
0
-
> 1 Any 1 Start forward
Any 0
-
> 1 1 Start reverse
Any Any 0 Stop
