204 Parameters
In1 Start fwd; In2
Start rev
The source selected by 20.08 Ext2 in1 source is the forward
start signal; the source selected by 20.09 Ext2 in2 source is
the reverse start signal. The state transitions of the source
bits are interpreted as follows:
3
In1P Start; In2 Stop The sources of the start and stop commands are selected by
parameters 20.08 Ext2 in1 source and 20.09 Ext2 in2 source.
The state transitions of the source bits are interpreted as
follows:
Notes:
• Parameter 20.07 Ext2 start trigger type has no effect with
this setting.
• When source 2 is 0, the Start and Stop keys on the control
panel are disabled.
4
In1P Start; In2 Stop;
In3 Dir
The sources of the start and stop commands are selected by
parameters 20.08 Ext2 in1 source and 20.09 Ext2 in2 source.
The source selected by 20.10 Ext2 in3 source determines the
direction. The state transitions of the source bits are
interpreted as follows:
Notes:
• Parameter 20.07 Ext2 start trigger type has no effect with
this setting.
• When source 2 is 0, the Start and Stop keys on the control
panel are disabled.
5
No. Name/Value Description Def/FbEq16
State of source 1
(20.08)
State of source 2
(20.09)
Command
00Stop
0 -> 1 (20.07 = Edge)
1 (20.07 = Level)
0 Start forward
0
0 -> 1 (20.07 = Edge)
1 (20.07 = Level)
Start reverse
11Stop
State of source 1
(20.08)
State of source 2
(20.09)
Command
0
-
> 1 1 Start
Any 0 Stop
State of
source 1
(20.08)
State of
source 2
(20.09)
State of
source 3
(20.10)
Command
0
-
> 1 1 0 Start forward
0
-
> 1 1 1 Start reverse
Any 0 Any Stop
