Parameters 203
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
Timed function 1 Bit 0 of 34.01 Timed functions status (see page 273). 18
Timed function 2 Bit 1 of 34.01 Timed functions status (see page 273). 19
Timed function 3 Bit 2 of 34.01 Timed functions status (see page 273). 20
Supervision 1 Bit 0 of 32.01 Supervision status (see page 266). 24
Supervision 2 Bit 1 of 32.01 Supervision status (see page 266). 25
Supervision 3 Bit 2 of 32.01 Supervision status (see page 266). 26
Other [bit] Source selection (see Terms and abbreviations on page 162). -
20.04 Ext1 in2 source Selects source 2 for parameter 20.01 Ext1 commands.
For the available selections, see parameter 20.03 Ext1 in1
source.
DI2
20.05 Ext1 in3 source Selects source 3 for parameter 20.01 Ext1 commands.
For the available selections, see parameter 20.03 Ext1 in1
source.
Always off
20.06 Ext2 commands Selects the source of start, stop and direction commands for
external control location 2 (EXT2).
See also parameters 20.07…20.10
. See parameter 20.21 for
the determination of the actual direction.
Not selected
Not selected No start or stop command sources selected. 0
In1 Start The source of the start and stop commands is selected by
parameter 20.08 Ext2 in1 source. The state transitions of the
source bits are interpreted as follows:
1
In1 Start; In2 Dir The source selected by 20.08 Ext2 in1 source is the start
signal; the source selected by 20.09 Ext2 in2 source
determines the direction. The state transitions of the source
bits are interpreted as follows:
2
No. Name/Value Description Def/FbEq16
State of source 1 (20.08) Command
0 -> 1 (20.07 = Edge)
1 (20.07 = Level)
Start
0Stop
State of source 1
(20.08)
State of source 2
(20.09)
Command
0 Any Stop
0 -> 1 (20.07 = Edge)
1 (20.07 = Level)
0 Start forward
1 Start reverse
