Parameters 221
22.22 Constant speed
sel1
When bit 0 of parameter 22.21 Constant speed function is 0
(Separate), selects a source that activates constant speed 1.
When bit 0 of parameter 22.21 Constant speed function is 1
(Packed), this parameter and parameters 22.23 Constant
speed sel2 and 22.24 Constant speed sel3 select three
sources whose states activate constant speeds as follows:
DI3
Always off 0 (always off). 0
Always on 1 (always on). 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
Timed function 1 Bit 0 of 34.01 Timed functions status (see page 273). 18
Timed function 2 Bit 1 of 34.01 Timed functions status (see page 273). 19
Timed function 3 Bit 2 of 34.01 Timed functions status (see page 273). 20
Supervision 1 Bit 0 of 32.01 Supervision status (see page 266). 24
Supervision 2 Bit 1 of 32.01 Supervision status (see page 266). 25
Supervision 3 Bit 2 of 32.01 Supervision status (see page 266). 26
Other [bit] Source selection (see Terms and abbreviations
on page 162). -
22.23 Constant speed
sel2
When bit 0 of parameter 22.21 Constant speed function is 0
(Separate), selects a source that activates constant speed 2.
When bit 0 of parameter 22.21 Constant speed function is 1
(Packed), this parameter and parameters 22.22 Constant
speed sel1 and 22.24 Constant speed sel3 select three
sources that are used to activate constant speeds. See table
at parameter 22.22 Constant speed sel1.
For the selections, see parameter 22.22 Constant speed sel1.
DI4
22.24 Constant speed
sel3
When bit 0 of parameter 22.21 Constant speed function is 0
(Separate), selects a source that activates constant speed 3.
When bit 0 of parameter 22.21 Constant speed function is 1
(Packed), this parameter and parameters 22.22 Constant
speed sel1 and 22.23 Constant speed sel2 select three
sources that are used to activate constant speeds. See table
at parameter 22.22 Constant speed sel1.
For the selections, see parameter 22.22 Constant speed sel1.
Always off
No. Name/Value Description Def/FbEq16
Source defined
by par. 22.22
Source defined
by par. 22.23
Source defined
by par. 22.24
Constant speed active
000 None
1 0 0 Constant speed 1
0 1 0 Constant speed 2
1 1 0 Constant speed 3
0 0 1 Constant speed 4
1 0 1 Constant speed 5
0 1 1 Constant speed 6
1 1 1 Constant speed 7
