Parameters 275
34.11 Timer 1
configuration
Defines when timer 1 is active. 0b0111
0b0000...0b1111 Configuration of timer 1. 1 = 1
34.12 Timer 1 start time Defines the daily start time of timer 1. The time can be
changed in second steps.
The timer can be started at an other time than the start time.
E.g. if the timer's duration is more than one day and the active
session starts during the time, the timer is started at 00:00
and stopped when there is no duration left.
00:00:00
00:00:00…23:59:59 Daily start time of the timer. 1 = 1
34.13 Timer 1 duration Defines the duration of timer 1. The duration can be changed
in minute steps.
The duration can extend over the change of the day but if an
exception day becomes active, the period is interrupted at
midnight. In the same way the period started on an exception
day stays active only until the end of the day, even if the
duration is longer. The timer will continue after a break if there
is duration left.
00 00:00
00 00:00…07 00:00 Timer duration. 1 = 1
34.14 Timer 2
configuration
See 34.11 Timer 1 configuration. 0b0111
34.15 Timer 2 start time See 34.12 Timer 1 start time. 00:00:00
34.16 Timer 2 duration See 34.13 Timer 1 duration. 00 00:00
34.17 Timer 3
configuration
See 34.11 Timer 1 configuration. 0b0111
No. Name/Value Description Def/FbEq16
Bit Name Description
0 Monday 1 = Monday is an active start day.
1 Tuesday 1 = Tuesday is an active start day.
2 Wednesday 1 = Wednesday is an active start day.
3 Thursday 1 = Thursday is an active start day.
4 Friday 1 = Friday is an active start day.
5 Saturday 1 = Saturday is an active start day.
6 Sunday 1 = Sunday is an active start day.
7 Season 1 1 = Timer is active in season 1.
8 Season 2 1 = Timer is active in season 2.
9 Season 3 1 = Timer is active in season 3.
10 Season 4 1 = Timer is active in season 4.
11 Exceptions 0 = Exceptions days are disabled.
1 = Exception days are enabled. Bits 12 and 13 are taken
into account.
12 Holidays 0 = Timer is inactive on exception days configured as
“Holiday”.
1 = Timer is active on exception days configured as
“Holiday”.
13 Workdays 0 = Timer is inactive on exception days configured as
“Workday”.
1 = Timer is active on exception days configured as
“Workday”.
14…15 Reserved
