Parameters 325
AO2 data storage 13.92 AO2 data storage.38
Other Source selection (see Terms and abbreviations on page 162). -
49.20 Basic panel home
view 2
Selects the parameters that is shown in Home view 2 of the
Basic panel (ACS-BP-S) when the active external control
location is EXT1.
Home view 2 is toggled automatically between Home view 5
(parameter 49.21) according to the active external control
location EXT1 or EXT2, respectively
See parameter 49.19 for the other selections than Auto.
Auto
Auto 01.07 Motor current (page 165) . 0
49.21 Basic panel home
view 3
Selects the parameters that is shown in Home view 3 of the
Basic panel (ACS-BP-S) when the active external control
location is EXT1.
Home view 3 is toggled automatically between Home view 6
(parameter 49.221) according to the active external control
location EXT1 or EXT2, respectively
See parameter 49.19 for the other selections than Auto.
Auto
Auto 01.10 Motor torque (page 165)0
49.21 Basic panel home
view 3
Selects the parameters that is shown in Home view 4 of the
Basic panel (ACS-BP-S) when the active external control
location is EXT2.
Home view 1 is toggled automatically between Home view 4
(parameter 49.19) according to the active external control
location EXT1 or EXT2, respectively.
See parameter 49.19 for the other selections than Auto.
Auto
Auto Selects the same parameter as selected by parameter 49.19
Basic panel home view 1 for external control location EXT 1.
0
49.21 Basic panel home
view 3
Selects the parameters that is shown in Home view 5 of the
Basic panel (ACS-BP-S) when the active external control
location is EXT2.
Home view 2 is toggled automatically between Home view 5
(parameter 49.20) according to the active external control
location EXT1 or EXT2, respectively.
See parameter 49.19 for the other selections than Auto.
Auto
Auto Selects the same parameter as selected by parameter 49.20
Basic panel home view 2 for external control location EXT 1.
0
49.221 Basic panel home
view 6
Selects the parameters that is shown in Home view 6 of the
Basic panel (ACS-BP-S) when the active external control
location is EXT2.
Home view 3 is toggled automatically between Home view 6
(parameter 49.21) according to the active external control
location EXT1 or EXT2, respectively.
See parameter 49.19 for the other selections than Auto.
Auto
Auto Selects the same parameter as selected by parameter 49.21
Basic panel home view 3 for external control location EXT 1.
0
No. Name/Value Description Def/FbEq16
