Override speed/freq Parameter 70.06 Override frequency/ 70.07 Override speed
is used as the reference.
3
Motor
potentiometer
22.80 Motor potentiometer ref act (output of the Motor
potentiometer)
4
Stop The output of the drive is shut off and the motor no longer
runs. Override is displayed on the panel but the motor does
not run. Drive follows the specified stop type.
5
Process PID set 1 Output of the process PID Set 1 (40.96) is used as the
reference.
6
70.05 Override direction Selects the source of the motor direction used in the override
mode.
Forward
Forward Direction is forward. 0
Reverse Direction is reverse. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
-DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 8
-DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 9
-DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 10
-DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 11
-DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 12
-DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 13
Other [bit] Source selection (see Terms and abbreviations on page 162). -
70.06 Override frequency Defines the frequency used as reference in the override
mode if 70.04 Override reference source is set to Override
speed/freq and the drive is in frequency mode..
0.0 Hz
-500.0…500.0 Hz Override frequency. 1 = 1 Hz
70.07 Override speed Defines the speed used as reference in the override mode if
70.04 Override reference source is set to Override speed/freq
and the drive is in speed mode.
0.0 rpm
-30000.0…
30000.0 rpm
Override speed. 1 = 1 rpm
70.20 Override fault
handling
Faults are grouped into high priority faults and low priority
faults. The following faults are high priority, and they are
displayed and they will stop the drive:
2310 Overcurrent, 2340 Short circuit, 3210 DC link
overvoltage, 4981 External temperature 1, 4982 External
temperature 2, 5090 STO hardware failure, 5091 Safe torque
off, FA81 Safe torque off 1, FA81 Safe torque off 2.
Other faults are low priority faults. Active low priority faults are
reset when the drive enters override mode. Low priority faults
are ignored when the drive is in override mode.
Fault on high
priority
Fault on high
priority
Fault on high priority faults. The fault must be reset from the
control panel or from a digital input.
0
No. Name/Value Description Def/FbEq16
