346 Parameters
inactive (ext1
active)
-9
Running with VSD - 100
Running with VSD
+ 1 Aux
- 101
Running with VSD
+ 2 Aux
- 102
Running with VSD
+ 3 Aux
- 103
Starting Aux1 - 200
Starting Aux2 - 201
Starting Aux3 - 202
Stopping Aux1 - 300
Stopping Aux2 - 301
Stopping Aux3 - 302
Autochange active - 400
No auxiliary motors
available to be
started
- 500
Regulator bypass
active
- 600
MPFC connection
ok
- 700
PID sleep - 800
PID sleep boost - 801
76.11 Pump/fan status 1 Shows the status of pump or fan 1. 0b0000
0b0000…0b1111 Status of pum p or fan 1 . 1 = 1
76.12 Pump/fan status 2 See parameter 76.11 Pump/fan status 1.-
76.13 Pump/fan status 3 See parameter 76.11 Pump/fan status 1.-
76.14 Pump/fan status 4 See parameter 76.11 Pump/fan status 1.-
76.21 PFC configuration Selects the multi-pump/fan control (PFC) mode. Off
Off PFC disabled. 0
No. Name/Value Description Def/FbEq16
Bit Name Value
0 Ready 0 = False, 1 = True
2 Running 0 = False, 1 = True
5 In PFC control 0 = False, 1 = True
1, 3, 4,
6…10
Reserved
11 Interlocked 0 = False, 1 = True
12…15 Reserved
