406 Additional parameter data
95.04 Control board supply List 0…1 - 1 = 1
95.15 Special HW settings PB 0b0000…0b1111 - 1 = 1
95.20 HW options word 1 PB 0b0000…0b1111 - 1 = 1
95.21 HW options word 2 PB 0b0000…0b1111 - 1 = 1
95.200 Cooling fan mode List 0, 1 - 1 = 1
96 System
96.01 Language List 0, 1033, 2052 - 1 = 1
96.02 Pass code Data --1 = 1
96.03 Access level status PB 0b0000...0b1111 - 1 = 1
96.04 Macro select List --1 = 1
96.05 Macro active List --1 = 1
96.06 Parameter restore List 0, 2, 8, 32, 62, 512, 1024,
34560
-1 = 1
96.07 Parameter save manually List 0, 1 - 1 = 1
96.08 Control board boot List 0, 1 - 1 = 1
96.10 User set status List 0...11 - 1 = 1
96.11 User set save/load List 0...5, 18...21 - 1 = 1
96.12 User set I/O mode in1 Binary
src
--1=1
96.13 User set I/O mode in2 Binary
src
--1=1
96.16 Unit selection PB 0b0000...0b1111 - 1 = 1
96.20 Time sync primary source List --1 = 1
96.51 Clear fault and event logger Real 0…1 - 1 = 1
(Parameters 96.100…96.102 only visible when enabled by parameter 96.02)
96.78 550 compatibility mode List 0...1 - 1 = 1
96.100 Change user pass code Data 10000000…99999999 - 1 = 1
96.101 Confirm user pass code Data 10000000…99999999 - 1 = 1
96.102 User lock functionality PB 0000h…FFFFh - 1 = 1
97 Motor control
97.01 Switching frequency reference List 2, 4, 8, 12 kHz 1 = 1 kHz
97.02 Minimum switching frequency List 1.5, 2, 4, 8, 12 kHz 1 = 1 kHz
97.03 Slip gain Real 0…200 % 1 = 1%
97.04 Voltage reserve Real -4…50 % 1 = 1%
97.05 Flux braking List 0…2 - 1 = 1
97.08 Optimizer minimum torque Real 0.0...1600.0 % 1 = 1
97.13 IR compensation Real 0.00…50.00 % 100 = 1%
97.20 U/F ratio List 0…20 - 1 = 1
97.49 Slip gain for scalar Real 0...200 % 1 = 1%
97.94 IR comp max frequency Real 1.0...200.0 % 10 = 1%
98 User motor parameters
98.01 User motor model mode List 0…1 - 1 = 1
No. Name Type Range Unit FbEq32
