Fault tracing 433
004 Underload occurred between
speed point 37.14 ULC speed
table point 4 and 37.15 ULC
speed table point 5.
Check the load.
8002 ULC overload fault User load curve: Signal has
been too long over the
overload curve.
See parameter 37.03 ULC overload
actions.
001 Overload occurred between
speed point 37.11 ULC speed
table point 1 and 37.12 ULC
speed table point 2.
Check the load.
002 Overload occurred between
speed point 37.12 ULC speed
table point 2 and 37.13 ULC
speed table point 3.
Check the load.
003 Overload occurred between
speed point 37.13 ULC speed
table point 3 and 37.14 ULC
speed table point 4.
Check the load.
004 Overload occurred between
speed point 37.14 ULC speed
table point 4 and 37.15 ULC
speed table point 5.
Check the load.
8009 Current limit Motor actual current exceeded
the limit defined in parameter
30.17 Maximum current.
Reduce the motor load. Check for any
jam or stall in motor.
See parameter 30.17 Maximum current.
80A0 AI supervision
Programmable fault:
12.03 AI supervision
function
An analog signal is outside the
limits specified for the analog
input
Check signal level at the analog input.
Check the auxiliary code.
Check the wiring connected to the input.
Check the minimum and maximum limits
of the input in parameter group 12
Standard AI.
80B0 Signal supervision 1
(Editable message text)
Programmable fault:
32.06 Supervision 1 action
Fault generated by the signal
supervision function 1.
Check the source of the fault (parameter
32.07 Supervision 1 signal).
80B1 Signal supervision 2
(Editable message text)
Programmable fault:
32.16 Supervision 2 action
Fault generated by the signal
supervision function 2.
Check the source of the fault (parameter
32.17 Supervision 2 signal).
80B2 Signal supervision 3
(Editable message text)
Programmable fault:
32.26 Supervision 3 action
Fault generated by the signal
supervision function 3.
Check the source of the fault (parameter
32.27 Supervision 3 signal).
80B3 Signal supervision 4
(Editable message text)
Programmable fault:
32.36 Supervision 4 action
Fault generated by the signal
supervision function 4.
Check the source of the fault (parameter
32.37 Supervision 4 signal).
Code
(hex)
Fault / Aux. code (aux
code visible only on
assistant control panel
and drive composer)
Cause What to do
1 – AI1LessMIN 3 – AI2LessMIN
2 – AI1GreaterMAX 4 – AI2GreaterMAX
