Parameters 267
Abs high Action is taken whenever the absolute value of the signal
rises above its (absolute) high limit.
4
Both Action is taken whenever the signal falls below its low limit or
rises above its high limit.
5
Abs both Action is taken whenever the absolute value of the signal falls
below its (absolute) low limit or rises above its (absolute) high
limit.
6
Hysteresis Action is taken whenever the signal rises above the value
defined by the high limit + 0.5 hysteresis. The action is
deactivated when the signal falls below the value defined by
the low limit - 0.5 hysteresis.
7
32.06 Supervision 1
action
Selects whether the drive generates a fault, warning or
neither when the value monitored by signal supervision 1
exceeds its limits.
Note: This parameter does not affect the status indicated by
32.01 Supervision status.
No action
No action No warning or fault generated. 0
Warning Warning A8B0 Signal supervision 1 is generated. 1
Fault Drive trips on fault 80B0 Signal supervision 1.2
Fault if running If running, the drive trips on fault 80B0 Signal supervision 1.3
32.07 Supervision 1
signal
Selects the signal to be monitored by signal supervision
function 1.
Frequency
Zero None. 0
Speed 01.01 Motor speed used (page 165). 1
Frequency 01.06 Output frequency (page 165). 3
Current 01.07 Motor current (page 165). 4
Torque 01.10 Motor torque (page 165). 6
DC voltage 01.11 DC voltage (page 165). 7
Output power 01.14 Output power (page 166). 8
AI1 12.11 AI1 actual value (page 189). 9
AI2 12.21
AI2 actual value (page 191). 10
Inverter
temperature
05.11 Inverter temperature (page 171). 23
Process PID output 40.01 Process PID output actual (page 295). 24
Process PID
feedback
40.02 Process PID feedback actual (page 295). 25
Process PID
setpoint
40.03 Process PID setpoint actual (page 295). 26
Process PID
deviation
40.04 Process PID deviation actual (page 295). 27
Other Source selection (see Terms and abbreviations on page 162). -
32.08 Supervision 1 filter
time
Defines a filter time constant for the signal monitored by
signal supervision 1.
0.000 s
0.000 … 30.000 s Signal filter time. 1000 = 1 s
32.09 Supervision 1 low Defines the lower limit for signal supervision 1. 0.00
-21474836.00…
21474836.00
Low limit. -
No. Name/Value Description Def/FbEq16
