420 Fault tracing
0003 Relay output 3 Select a different signal with parameter
10.30 RO3 source.
A8B0 Signal supervision 1
(Editable message text)
Programmable warning:
32.06 Supervision 1 action
Warning generated by the
signal supervision function 1.
Check the source of the warning
(parameter 32.07 Supervision 1 signal).
A8B1 Signal supervision 2
(Editable message text)
Programmable warning:
32.16 Supervision 2 action
Warning generated by the
signal supervision function 2.
Check the source of the warning
(parameter 32.17 Supervision 2 signal).
A8B2 Signal supervision 3
(Editable message text)
Programmable warning:
32.26 Supervision 3 action
Warning generated by the
signal supervision function 3.
Check the source of the warning
(parameter 32.27 Supervision 3 signal).
A8B3 Signal supervision 4
(Editable message text)
Programmable warning:
32.36 Supervision 4 action
Warning generated by the
signal supervision function 4.
Check the source of the warning
(parameter 32.37 Supervision 4 signal).
A8B4 Signal supervision 5
(Editable message text)
Programmable warning:
32.46 Supervision 5 action
Warning generated by the
signal supervision function 5.
Check the source of the warning
(parameter 32.47 Supervision 5 signal).
A8B5 Signal supervision 6
(Editable message text)
Programmable warning:
32.56 Supervision 6 action
Warning generated by the
signal supervision function 6.
Check the source of the warning
(parameter 32.57 Supervision 6 signal).
A8B6 Current limit Motor actual current exceeded
the limit defined in parameter
30.17 Maximum current.
Reduce the motor load. Check for any
jam or stall in motor.
A8BE ULC overload warning User load curve: Signal has
been too long over the
overload curve.
See parameter 37.03 ULC overload
actions.
001 Overload occurred between
speed point 37.11 ULC speed
table point 1 and 37.12 ULC
speed table point 2.
Check the load.
002 Overload occurred between
speed point 37.12 ULC speed
table point 2 and 37.13 ULC
speed table point 3.
Check the load.
003 Overload occurred between
speed point 37.13 ULC speed
table point 3 and 37.14 ULC
speed table point 4.
Check the load.
004 Overload occurred between
speed point 37.14 ULC speed
table point 4 and 37.15 ULC
speed table point 5.
Check the load.
A8BF ULC underload
warning
User load curve: Signal has
been too long under the
underload curve.
See parameter 37.04 ULC underload
actions.
Code
(hex)
Warning / Aux. code
(aux code visible only
on assistant control
panel and drive
composer)
Cause What to do
