Fault tracing 435

FF61 ID run Motor ID run was not

completed successfully.

Check the nominal motor values in

parameter group 99 Motor data.

Check that no external control system is

connected to the drive.

Cycle the power to the drive (and its

control unit, if powered separately).

Check that no operation limits prevent

the completion of the ID run. Restore

parameters to default settings and try

again.

Check that the motor shaft is not locked.

0001 Maximum current limit too low. Check settings of parameters 99.06

Motor nominal current and 30.17

Maximum current. Make sure that

30.17 > 99.06.

Check that the drive is dimensioned

correctly according to the motor.

0002 Maximum speed limit or

calculated field weakening

point too low.

Check settings of parameters

• 30.11 Minimum speed

• 30.12 Maximum speed

• 99.07 Motor nominal voltage

• 99.08 Motor nominal frequency

• 99.09 Motor nominal speed.

Make sure that

• 30.12 > (0.55 × 99.09) >

(0.50 × synchronous speed)

• 30.11 <

0, and

• supply voltage >

(0.66 × 99.07).

0003 Maximum torque limit too low. Check settings of parameter 99.12 Motor

nominal torque, and the torque limits in

group 30 Limits.

Make sure that the maximum torque limit

in force is greater than 100%.

0004 Current measurement

calibration did not finish within

reasonable time
