100 Parameters
04.13 3rd latest fault Code of the 3rd stored (non-active) fault. -
0000h…FFFFh 3rd stored fault. 1 = 1
04.14 4th latest fault Code of the 4th stored (non-active) fault. -
0000h…FFFFh 4th stored fault. 1 = 1
04.15 5th latest fault Code of the 5th stored (non-active) fault. -
0000h…FFFFh 5th stored fault. 1 = 1
04.16 Latest warning Code of the 1st stored (non-active) warning. -
0000h…FFFFh 1st stored warning. 1 = 1
04.17 2nd latest warning Code of the 2nd stored (non-active) warning. -
0000h…FFFFh 2nd stored warning. 1 = 1
04.18 3rd latest warning Code of the 3rd stored (non-active) warning. -
0000h…FFFFh 3rd stored warning. 1 = 1
04.19 4th latest warning Code of the 4th stored (non-active) warning. -
0000h…FFFFh 4th stored warning. 1 = 1
04.20 5th latest warning Code of the 5th stored (non-active) warning. -
0000h…FFFFh 5th stored warning. 1 = 1
04.25 Faulted modules (Only visible with a BCU control unit)
Indicates which parallel-connected modules have faulted.
The bits of this word are cleared when all faults have been
reset.
This parameter is read-only.
-
0000h…FFFFh Faulted modules indication. 1 = 1
0000h…FFFFh ACS800-compatible warning (alarm) word 2. 1 = 1
04.40 Event word 1 User-defined event word. This word collects the status of the
events (warnings, faults or pure events) selected by
parameters 04.41…04.72.
For each event, an auxiliary code can optionally be specified
for filtering.
This parameter is read-only.
-
0000h…FFFFh User-defined event word. 1 = 1
No. Name/Value Description Def/FbEq16
Bit Name Description
0 Module 1 1 = Module 1 faulted
1 Module 2 1 = Module 2 faulted
…… …
11 Module 12 1 = Module 12 faulted
12…15 Reserved
Bit Name Description
0 User bit 0 1 = Event selected by parameters 04.41 (and 04.42) is active
1 User bit 1 1 = Event selected by parameters 04.43 (and 04.44) is active
…… …
15 User bit 15 1 = Event selected by parameters 04.71 (and 04.72) is active
