112 Parameters
07.30 Adaptive program
status
Shows the status of the adaptive program.
See section Adaptive programming (page 27).
-
0000h…FFFFh Adaptive program status. 1 = 1
07.40 IEC application Cpu
usage peak
(Only visible with option +N8010 [application
programmability])
Displays the peak loading of the microprocessor caused by
the application program. This parameter can, for example, be
used to check the effect of a given application program
functionality on the CPU load.
The value is in percent of an internal quota.
Can be reset from the control panel by keeping Reset
depressed for over 3 seconds.
-
0.0 … 100.0% Peak microprocessor loading caused by application program. 10 = 1%
07.41 IEC application Cpu
load average
(Only visible with option +N8010 [application
programmability])
Displays the average loading of the microprocessor caused
by the application program. The value is in percent of an
internal quota.
-
0.0 … 100.0% Average microprocessor loading caused by application
program.
10 = 1%
07.51 Slot 1 option
module
Displays the type of module detected in slot 1 of the drive
control unit.
No option
No option No module detected. 0
[module type] Type of module detected. -
07.52 Slot 2 option
module
Displays the type of module detected in slot 2 of the drive
control unit.
No option
No option No module detected. 0
[module type] Type of module detected. -
[module type] Type of module detected. -
No. Name/Value Description Def/FbEq16
Bit Name Description
0 Initialized 1 = Adaptive program initialized
1 Editing 1 = Adaptive program is being edited
2 Edit done 1 = Editing of adaptive program finished
3 Running 1 = Adaptive program running
4…13 Reserved
14 State changing Reserved
15 Faulted 1 = Error in adaptive program
