204 Parameters
31.22 Drive interlocked Selects which indications are given when one or both Drive
interlock (DIL) signals are switched off or lost. The indications
also depend on whether the drive is running or stopped when
this occurs.
The tables at each selection below show the indications
generated with that particular setting.
Notes:
• This parameter does not affect the operation of the DIL
function itself. The DIL function will operate regardless of
the setting of this parameter: a running drive will stop upon
removal of one or both DIL signals, and will not start until
both DIL signals are restored and all faults reset.
• The loss of only one DIL signal always generates a fault as
it is interpreted as a malfunction.
• This parameter cannot be changed while the drive is
running.
For more information on the DIL, see the Hardware manual of
the drive.
Fault/Fault
Fault/Fault 0
Fault/Warning 1
No. Name/Value Description Def/FbEq16
Inputs
Indication (running or stopped)
IN1 IN2
00 Fault 5091 Drive interlock
01
Faults 5091 Drive interlock and FA81 Drive
interlock 1 loss
10
Faults 5091 Drive interlock and FA82 Drive
interlock 2 loss
1 1 (Normal operation)
Inputs Indication
IN1 IN2 Running Stopped
00
Fault 5091 Drive
interlock
Warning A5A0 Drive
interlock
01
Faults 5091 Drive
interlock and FA81
Drive interlock 1 loss
Warning A5A0 Drive
interlock and fault
FA81 Drive interlock 1
loss
10
Faults 5091 Drive
interlock and FA82
Drive interlock 2 loss
Warning A5A0 Drive
interlock and fault
FA82 Drive interlock 2
loss
1 1 (Normal operation)
