230 Parameters
Output frequency 01.06 Output frequency (page 95). 3
Motor current 01.07 Motor current (page 95). 4
Motor torque 01.10 Motor torque (page 95). 6
DC voltage 01.11 DC voltage (page 95). 7
Power inu out 01.14 Output power (page 95). 8
Speed ref ramp in 23.01 Speed ref ramp input (page 157). 10
Speed ref ramped 23.02 Speed ref ramp output (page 157). 11
Speed ref used 24.01 Used speed reference (page 162). 12
Torq ref used 26.02 Torque reference used (page 178). 13
Freq ref used 28.02 Frequency ref ramp output (page 186). 14
Other Source selection (see Terms and abbreviations on page 92). -
36.02 PVL filter time Defines a filtering time for the peak value logger. See
parameter 36.01 PVL signal source.
2.00 s
0.00 … 120.00 s Peak value logger filtering time. 100 = 1 s
36.06 AL2 signal source Selects the signal to be monitored by amplitude logger 2. The
signal is sampled at 200 ms intervals, and can be scaled
using parameter 36.07 AL2 signal scaling.
The results are displayed by parameters 36.40…36.49. Each
parameter represents an amplitude range, and shows what
portion of the samples fall within that range.
Amplitude logger 2 can be reset using parameter 36.09
Reset
loggers. The logger is also reset whenever the signal source
or scaling is changed. The date and time of the last reset are
stored into parameters 36.50 and 36.51 respectively.
Ambient
temperature
Zero None (amplitude logger 2 disabled). 0
Motor speed used 01.01 Motor speed used (page 95). 1
Output frequency 01.06 Output frequency (page 95). 3
Motor current 01.07 Motor current (page 95). 4
Motor torque 01.10 Motor torque (page 95). 6
DC voltage 01.11 DC voltage (page 95). 7
Power inu out 01.14 Output power (page 95). 8
Speed ref ramp in 23.01 Speed ref ramp input (page 157). 10
Speed ref ramped 23.02 Speed ref ramp output (page 157). 11
Speed ref used 24.01 Used speed reference (page 162). 12
Torq ref used 26.02 Torque reference used (page 178). 13
Freq ref used 28.02 Frequency ref ramp output (page 186). 14
Ambient
temperature
01.70 Ambient temperature % (page 98).
The amplitude range of 0…100% corresponds to 0…60 °C
20
Other Source selection (see Terms and abbreviations
on page 92). -
36.07 AL2 signal scaling Defines the signal value that corresponds to 100% amplitude. 100.00
0.00 … 32767.00 Signal value corresponding to 100%. 1 = 1
No. Name/Value Description Def/FbEq16
