262 Parameters
58.36 EFB comm
supervision force
Activates fieldbus communication monitoring separately for
each control location (see section Local control vs. external
control on page 20).
The parameter is primarily intended for monitoring the
communication with EFB when it is connected to the
application program and not selected as a control source by
drive parameters.
0000b
0000b…0111b EFB communication monitoring selection. 1 = 1
58.101 Data I/O 1 Defines the address in the drive which the Modbus master
accesses when it reads from or writes to register address
400001.
The master defines the type of the data (input or output). The
value is transmitted in a Modbus frame consisting of two 16-
bit words. If the value is 16-bit, it is transmitted in the LSW
(least significant word). If the value is 32-bit, the subsequent
parameter is also reserved for it and must be set to None.
CW 16bit
None None. 0
CW 16bit Control Word (16 bits). 1
Ref1 16bit Reference REF1 (16 bits). 2
Ref2 16bit Reference REF2 (16 bits). 3
SW 16bit Status Word (16 bits). 4
Act1 16bit Actual value ACT1 (16 bits). 5
Act2 16bit Actual value ACT2 (16 bits). 6
CW 32bit Control Word (32 bits). 11
Ref1 32bit Reference REF1 (32 bits). 12
Ref2 32bit Reference REF2 (32 bits). 13
SW 32bit Status Word (32 bits). 14
Act1 32bit Actual value ACT1 (32 bits). 15
Act2 32bit Actual value ACT2 (32 bits). 16
CW2 16bit Control Word 2 (16 bits).
When a 32-bit control word is used, this setting means the
most-significant 16 bits.
21
SW2 16bit Status Word 2 (16 bits).
When a 32-bit control word is used, this setting means the
most-significant 16 bits.
24
RO/DIO control
word
Parameter 10.99 RO/DIO control word.31
AO1 data storage Parameter 13.91 AO1 data storage.32
AO2 data storage Parameter 13.92 AO2 data storage.33
Other Source selection (see Terms and abbreviations on page 92). -
No. Name/Value Description Def/FbEq16
Bit Name Value
0 Ext 1 1 = Communication monitoring active when Ext 1 is being used.
1 Ext 2 1 = Communication monitoring active when Ext 2 is being used.
2 Local 1 = Communication monitoring active when local control is being
used.
3…15 Reserved
