Parameters 261
Other Source selection (see Terms and abbreviations on page 92). -
58.32 EFB act2
transparent source
Selects the source of actual value 1 when 58.29 EFB act2
type is set to Transparent or General.
Not selected
Not selected None. 0
Other Source selection (see Terms and abbreviations on page 92). -
58.33 Addressing mode Defines the mapping between parameters and holding
registers in the 400101…465535 Modbus register range.
Changes to this parameter take effect after the control unit is
rebooted or the new settings validated by parameter 58.06
Communication control.
Mode 0
Mode 0 16-bit values (groups 1…99, indexes 1…99)
:
Register address = 400000 + 100 × parameter group +
parameter index. For example, parameter 22.80 would be
mapped to register 400000 + 2200 + 80 = 402280.
32-bit values (groups 1…99, indexes 1…99)
:
Register address = 420000 + 200 × parameter group +
2 × parameter index. For example, parameter 22.80 would be
mapped to register 420000 + 4400 + 160 = 424560.
0
Mode 1 16-bit values (groups 1…255, indexes 1…255)
:
Register address = 400000 + 256 × parameter group +
parameter index. For example, parameter 22.80 would be
mapped to register 400000 + 5632 + 80 = 405712.
1
Mode 2 32-bit values (groups 1…127, indexes 1…255)
:
Register address = 400000 + 512 × parameter group +
2 × parameter index. For example, parameter 22.80 would be
mapped to register 400000 + 11264 + 160 = 411424.
2
58.34 Word order Selects in which order 16-bit registers of 32-bit parameters
are transferred.
For each register, the first byte contains the high order byte
and the second byte contains the low order byte.
Changes to this parameter take effect after the control unit is
rebooted or the new settings validated by parameter 58.06
Communication control.
LO-HI
HI-LO The first register contains the high order word, the second
contains the low order word.
0
LO-HI The first register contains the low order word, the second
contains the high order word.
1
No. Name/Value Description Def/FbEq16
