260 Parameters
Torque The scaling is defined by parameter 46.03 Torque scaling.3
Speed The scaling is defined by parameter 46.01 Speed scaling.4
Frequency The scaling is defined by parameter 46.02 Frequency scaling.5
58.27 EFB ref2 type Selects the type and scaling of reference 2 received through
the embedded fieldbus interface.
The scaled reference is displayed by 03.10 EFB reference 2.
For the selections, see parameter 58.26 EFB ref1 type.
Torq ue
58.28 EFB act1 type Selects the type/source and scaling of actual value 1
transmitted to the fieldbus network through the embedded
fieldbus interface.
Auto
Auto Type/source and scaling follow the type of reference 1
selected by parameter 58.26 EFB ref1 type. See the individual
settings below for the sources and scalings.
0
Transparent The value selected by parameter 58.31 EFB act1 transparent
source is sent as actual value 1. No scaling is applied (the 16-
bit scaling is 1 = 1 unit).
1
General The value selected by parameter 58.31 EFB act1 transparent
source is sent as actual value 1 with a 16-bit scaling of 100 =
1 unit (ie. integer and two decimals).
2
To r q ue 01.10 Motor torque is sent as actual value 1. The scaling is
defined by parameter 46.03 Torque scaling.
3
Speed 01.01 Motor speed used is sent as actual value 1. The scaling
is defined by parameter 46.01 Speed scaling.
4
Frequency 01.06 Output frequency is sent as actual value 1. The scaling
is defined by parameter 46.02 Frequency scaling.
5
58.29 EFB act2 type Selects the type/source and scaling of actual value 2
transmitted to the fieldbus network through the embedded
fieldbus interface.
Torq ue
Auto Type/source and scaling follow the type of reference 2
selected by parameter 58.27 EFB ref2 type. See the individual
settings below for the sources and scalings.
0
Transparent The value selected by parameter 58.32 EFB act2 transparent
source is sent as actual value 2. No scaling is applied (the 16-
bit scaling is 1 = 1 unit).
1
General The value selected by parameter 58.32 EFB act2 transparent
source is sent as actual value 2 with a 16-bit scaling of 100 =
1 unit (ie. integer and two decimals).
2
To r q ue 01.10 Motor torque is sent as actual value 2. The scaling is
defined by parameter 46.03 Torque scaling.
3
Speed 01.01 Motor speed used is sent as actual value 2. The scaling
is defined by parameter 46.01 Speed scaling.
4
Frequency 01.06 Output frequency is sent as actual value 2. The scaling
is defined by parameter 46.02 Frequency scaling.
5
58.30 EFB status word
transparent source
Selects the source of the status word when 58.25 Control
profile is set to Transparent.
Not selected
Not selected None. 0
Other Source selection (see Terms and abbreviations on page 92). -
58.31 EFB act1
transparent source
Selects the source of actual value 1 when 58.28 EFB act1
type is set to Transparent or General.
Not selected
Not selected None. 0
No. Name/Value Description Def/FbEq16
