Parameters 309
Reduced Reduced ID run. This mode should be selected instead of the
Normal ID Run if
• mechanical losses are higher than 20% (i.e. the motor
cannot be de-coupled from the driven equipment), or if
• flux reduction is not allowed while the motor is running (i.e.
in case of a motor with an integrated brake supplied from
the motor terminals).
With this ID run mode, the resultant motor control in the field
weakening area or at high torques is not necessarily as
accurate as motor control following a Normal ID run. Reduced
ID run is completed faster than the Normal ID Run (< 90
seconds).
Note: Check the direction of rotation of the motor before
starting the ID run. During the run, the motor will rotate in the
forward direction.
WARNING! The motor will run at up to approximately
50…100% of the nominal speed during the ID run.
ENSURE THAT IT IS SAFE TO RUN THE MOTOR
BEFORE PERFORMING THE ID RUN!
2
Standstill Standstill ID run. The motor is injected with DC current. With
an AC induction (asynchronous) motor, the motor shaft is not
rotated. With a permanent magnet motor or synchronous
reluctance motor, the shaft can rotate up to half a revolution.
Note: A standstill ID run should be selected only if the Normal,
Reduced ID run is not possible due to the restrictions caused
by the connected mechanics (eg. with lift or crane
applications).s
3
99.14 Last ID run
performed
Shows the type of ID run that was performed last. For more
information about the different modes, see the selections of
parameter 99.13 ID run requested.
None
None No ID run has been performed. 0
Normal Normal ID run. 1
Reduced Reduced ID run. 2
Standstill Standstill ID run. 3
99.15 Motor polepairs
calculated
Calculated number of pole pairs in the motor. 0
0…1000 Number of pole pairs. 1 = 1
No. Name/Value Description Def/FbEq16
