ABB ControlMaster CM10 User Manual

ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN Appendix B – Error Codes
IM/CM/S–EN Rev. R 119
47 Dual Output Loop 2 Value 2
48 Mot Valve Output 1
49 Mot Valve Output 2
50 PV Maximum Value 1
51 PV Minimum Value 1
52 PV average Value 1
53 Volume Value 1
54 PV Maximum Value 2
55 PV Minimum Value 2
56 PV average Value 2
57 Volume Value 2
58 Customer Linearizer Value 1
59 Customer Linearizer Value 2
60 Profile User Value 1
61 Profile User Value 2
62 Mot Valve Position 1
63 Mot Valve Position 2
64 template Block PV Value 1
65 Template Block PV Value 2
66 Template Block
Deviation Value 1
Error
Code
Error Description
67 Template Block
Deviation Value 2
70 Analog Input Fail State A1
71 Analog Input Fail State A2
72 Analog Input Fail State B1
73 Analog Input Fail State B2
74 Analog Input Fail State C1
75 Analog Input Fail State C2
76 Maths Block Fail State 1
77 Maths Block Fail State 2
78 Maths Block Fail State 3
79 Maths Block Fail State 4
80 Maths Block Fail State 5
81 Maths Block Fail State 6
82 Maths Block Fail State 7
83 Maths Block Fail State 8
84 Custom Linearizer Fail State 1
85 Custom Linearizer Fail State 2
94 Analog Input State A1 (I/P 1)
95 Analog Input State A2 (I/P 2)
Error
Code
Error Description
96 Analog Input State B1
(I/P 3 – CM50)
97 Analog Input State B2
(I/P 4 – CM50)
98 Analog Input State C1
(I/P 3 – CM30)
99 Analog Input State C2
(I/P 4– CM30)
100 Setpoint Remote Mode State 1
101 Setpoint LSPT 1
Selected State 1
102 Setpoint LSPT 2
Selected State 1
103 Setpoint LSPT 3
Selected State 1
104 Setpoint LSPT 4
Selected State 1
105 Setpoint Remote
Mode State 2
106 Setpoint LSPT 1
Selected State 2
107 Setpoint LSPT 2
Selected State 2
Error
Code
Error Description
