ABB ControlMaster CM10 User Manual

ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN Appendix B – Error Codes
120 IM/CM/S–EN Rev. R
108 Setpoint LSPT 3
Selected State 2
109 Setpoint LSPT 4
Selected State 2
110 Digital Input State 1
111 Digital Input State 2
112 Digital Input State 3
113 Digital Input State 4
114 Digital Input State 5
115 Digital Input State 6
131 Logic Equation Result 1
132 Logic Equation Result 2
133 Logic Equation Result 3
134 Logic Equation Result 4
135 Logic Equation Result 5
136 Logic Equation Result 6
137 Logic Equation Result 7
138 Logic Equation Result 8
139 Real Time Alarm State 1
140 Real Time Alarm State 2
141 Alarm State 1
Error
Code
Error Description
142 Alarm Ack State 1
143 Alarm State 2
144 Alarm Ack State 2
145 Alarm State 3
146 Alarm Ack State 3
147 Alarm State 4
148 Alarm Ack State 4
149 Alarm State 5
150 Alarm Ack State 5
151 Alarm State 6
152 Alarm Ack State 6
153 Alarm State 7
154 Alarm Ack State 7
155 Alarm State 8
156 Alarm Ack State 8
157 Time Prop State 1
158 Time Prop State 2
159 Time Prop State 3
160 Time Prop State 4
161 Control O/P Auto State 1
Error
Code
Error Description
162 Control O/P Manual State 1
163 Control O/P Track Status 1
164 Control O/P Auto State 2
165 Control O/P Manual State 2
166 Control O/P Track Status 2
167 Analog O/P Loop break A1
168 Analog O/P Loop break B1
169 Mot Valve Close Relay State 1
170 Mot Valve Open Relay State 1
171 Mot Valve Sticking State 1
172 Mot Valve Tri State 1
173 Mot Valve Tri State 2
174 Mot Valve Close Relay State 2
175 Mot Valve Open Relay State 2
176 Mot Valve Sticking State 2
177 Delay Timer State 1
178 Delay Timer State 2
189 Toggle Signal
190 Edge Signal
Error
Code
Error Description
