ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
72 IM/CM/S–EN Rev. R
…Profile Parameters / …Common Settings
Ramp Control
Ramp Type Selects the Ramp Type required. The ramp type selected applies to all programs / segments.
The profile set point can be configured to increment in one of two way: for a fixed period of time
or for a number of engineering units per hour.
Rate
Defined as rate / time unit (hr, min, sec).
Time
Defined in hr:min:sec.
Ramp Units Selects the ramp rate time units required (Units/min, Units/hr, Units/sec).
Program Control
Run Selects the digital source used to start the program. The program is started on the rising edge.
Hold Selects the digital source used to put the program into 'Operator hold' mode.
Hold mode is entered on the rising edge.
