ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
IM/CM/S–EN Rev. R 73
…Profile Parameters / …Common Settings / …Program Control
Reset Selects the digital source used to reset a running program. The program is reset on a rising edge.
If the program was running, it will run from the start. If the program was held it will remain held at
the start point.
Run / Hold Selects the digital source used to start and hold the program. The program runs when the input
is high and holds when the input is low.
Stop Selects the digital source used to stop the program. The program is stopped on the rising edge.
Skip Selects the digital source used to skip to the next segment. The segment is skipped on the rising
edge.
Repeat Selects the digital source used to repeat the current segment. The segment is repeated on the
rising edge.
