Parameterization
102 FEX300, FEX500 OI/FEX300/FEX500-EN
Menu / Parameter Value range Description
Display / Operator Pages / Operator Page 1 (n)
Display Mode • 1 line with 6 characters.
• 1 line with 6 characters +
bar graph.
• 1 line with 9 characters.
• 1 line with 9 characters +
bar graph.
• 2 lines with 9 characters.
• 2 lines with 9 characters +
bar graph.
• 3 lines with 9 characters
(factory default).
• Graphic (line recorder)
• Off (the option disables the
respective operator page)
Configure each operator page. The following variants
in the value range can be selected:
1st Line
2nd Line
3st Line
• Flowrate [%]
• Flowrate [Unit]
• Totalizer Fwd
• Totalizer Rev
• Totalizer Net
• Flow Velocity [Unit]
• Current Output [mA]
• SignalProportion
• Reference
• Signal Max
• Signal Min
• Amplification
• Noise Reset Counter
• Total Batch Counter
1
• Batch Totalizer
1
• Conductivity
1
• Sensor Temp
1
Select the value displayed in each line. The following
variants in the value range can be selected:
Bargraph • Flowrate [%]
• Current Output [mA]
Select the value displayed in the bar graph. The
measuring values in the value range can be selected.
italics = Parameter can only be viewed at the "Advanced" password level.
1) Parameter / menu only available for FEP500 / FEH500.
