13 Functional and technical properties - ProcessMaster
Change from one to two colu mns
13.1 Flowmeter sensor
13.1.1 Protection type according to EN 60529
IP 65, P 67, NEMA 4X
IP 68 (for external flowmeter sensors only)
13.1.2 Pipeline vibration according to EN 60068-2-6
The following applies to compact devices:
(transmitter mounted directly on the flowmeter sensor)
• In the 10 ... 58 Hz range with max. 0.15 mm (0.006 inch)
deflection
• In the 58 ... 150 Hz range with max. 2 g acceleration
The following applies to devices with a separate transmitter:
Transmitter
• In the 10 ... 58 Hz range with max. 0.15 mm (0.006 inch)
deflection
• In the 58 ... 150 Hz range with max. 2 g acceleration
Flowmeter sensor
• In the 10 ... 58 Hz range with max. 0.15 mm (0.006 inch)
deflection
• In the 58 ... 150 Hz range with max. 2 g acceleration
13.1.3 Installation length
The flange devices comply with the installation lengths specified in
VDI/VDE 2641, ISO 13359, or according to DVGW (process sheet
W420, design WP, ISO 4064 short).
13.1.4 Signal cable (for external transmitters only)
A 5 m (16.4 ft) cable is supplied.
If you require more than 5 m (16,4 ft), a cable can be purchased using
order number D173D027U01.
For the transmitter designed for use in Zone 1, Div 1 (model FET325),
10 m (32.8 ft) of signal cable is permanently connected to the
transmitter.
Alternatively, the cable with order number AD173D031U01 can be
used for transmitters without explosion protection (model FEP321,
FEH321) from DN15 and for transmitters for use in Zone 2 (model
FEP325, FEH325) from DN15.
Preamplifier
Max. signal cable length between flowmeter sensor and transmitter:
a) Without preamplifier:
• Max. 50 m (164 ft) for conductivity ≥ 5 µS/cm
A preamplifier is required for cables > 50 m (164 ft).
b) With preamplifier
• Max. 200 m (656 ft) for conductivity ≥ 5 µS/cm
13.1.5 Temperature range
Storage temperature
-40 ... 70 °C (-40 ... 158 °F)
Min. permissible pressure as a function of fluid
temperature
Lining Nominal
diameter
POperating
mbar abs.
at
T
Operating
1)
Hard rubber 15 ... 2000
(1/2 ... 80")
0 < 90 °C (194 °F)
< 80 °C (176 °F)
2)
Soft rubber
50 ... 2000
(2 ... 80")
0 < 60 °C (140 °F)
PTFE
KTW-
approved
10 ... 600
(3/8 ... 24")
270
400
500
< 20 °C (68 °F)
< 100 °C (212 °F)
< 130 °C (266 °F)
Thick PTFE,
high-temp.
design
25 … 80
100 … 250
300
0
67
27
< 180 °C (356 °F)
< 180 °C (356 °F)
< 180 °C (356 °F)
PFA 3 ... 200
(1/10 ... 8")
0 < 180 °C (356 °F)
Elastomer
3)
50 .. 600
(2 … 24“)
100 < 130 °C (266 °F)
ETFE 25 ... 1000
(1 ... 40")
100 < 130 °C (266 °F)
Ceramic
Carbide
4)
25 ... 1000
(1 ... 40"
0 < 80 °C (176 °F)
1) For CIP/SIP cleaning, higher temperatures are permitted for limited time periods; refer to
the table titled "Maximum permissible cleaning temperature“.
2) Only China production site.
3) Only USA production site.
4) For FEP500 only.
Max. permissible cleaning temperature
CIP cleaning Sensor
lining
T
max
T
max
minutes
T
amb.
Steam cleaning
PTFE, PFA 150 °C
(302 °F)
60 25 °C
(77 °F)
Fluids
PTFE, PFA 140 °C
(284 °F)
60 25 °C
(77 °F)
If the ambient temperature is > 25 °C, the difference must be
subtracted from the max. cleaning temperature. T
max
- ∆ °C.
( ∆ °C = T
amb
- 25 °C)
