Functional and technical properties - ProcessMaster
OI/FEX300/FEX500-EN FEX300, FEX500 161
Important
When using the device in explosion hazardous areas, the additional temperature specifications in the section titled "Ex
relevant specifications" on the data sheet or in the the separate Ex safety instructions
(SM/FEX300/FEX500/ATEX/IECEX) or (SM/FEX300/FEX500/FM/CSA) must be observed.
Models FEP521, FEP525 (standard temperature version)
Ambient temperature Fluid temperature
Lining Flange material
Minimum temperature Max. temperature Minimum temperature Max. temperature
Hard rubber Steel -10 °C (14°F) 60 °C (140 °F) -10 °C (14°F)
90 °C (194 °F)
80 °C (176 °F)
4)
Hard rubber Stainless steel -15 °C (5 °F) 60 °C (140 °F) -15 °C (5 °F)
90 °C (194 °F)
80 °C (176 °F)
4)
Soft rubber
Steel
-10 °C (14°F) 60 °C (140 °F) -10 °C (14°F) 60 °C (140 °F)
Soft rubber
Stainless steel
-15 °C (5 °F) 60 °C (140 °F) -15 °C (5 °F) 60 °C (140 °F)
PTFE
Steel
-10 °C (14°F) 60 °C (140 °F) -10 °C (14°F) 130 °C (266 °F)
PTFE Stainless steel
-25 °C (-13 °F)
-40 °C (-40 °F)
5)
60 °C (140 °F) -25 °C (-13 °F) 130 °C (266 °F)
PFA
1)
Steel
-10 °C (14°F) 60 °C (140 °F) -10 °C (14°F) 130 °C (266 °F)
PFA
1)
Stainless steel
-25 °C (-13 °F)
-40 °C (-40 °F)
5)
60 °C (140 °F) -25 °C (-13 °F) 130 °C (266 °F)
Thick PTFE
2)
Steel
-10 °C (14°F) 60 °C (140 °F) -10 °C (14°F) 130 °C (266 °F)
Thick PTFE
2)
Stainless steel
-25 °C (-13 °F)
-40 °C (-40 °F)
5)
60 °C (140 °F) -25 °C (-13 °F) 130 °C (266 °F)
ETFE
3)
Steel
-10 °C (14°F) 60 °C (140 °F) -10 °C (14°F) 130 °C (266 °F)
ETFE
3)
Stainless steel
-25 °C (-13 °F) 60 °C (140 °F) -25 °C (-13 °F) 130 °C (266 °F)
Elastomer Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14°F) 130 °C (266 °F)
Elastomer Stainless steel -20 °C (-4 °F) 60 °C (140 °F) -20 °C (-4 °F) 130 °C (266 °F)
Ceramic carbide Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14°F) 80 °C (176 °F)
Ceramic carbide Stainless steel -25 °C (-13 °F) 60 °C (140 °F) -20 °C (-4 °F) 80 °C (176 °F)
Models FEP521, FEP525 (high-temperature version)
Ambient temperature Fluid temperature
Lining Flange material
Minimum temperature Max. temperature Minimum temperature Max. temperature
PFA
1)
Steel -10 °C (14°F) 60 °C (140 °F) -10 °C (14°F) 180 °C (356 °F)
PFA
1)
Stainless steel
-25 °C (-13 °F)
-40 °C (-40 °F)
5)
60 °C (140 °F) -25 °C (-13 °F) 180 °C (356 °F)
Thick PTFE
2)
Steel -10 °C (14°F) 60 °C (140 °F) -10 °C (14°F) 180 °C (356 °F)
Thick PTFE
2)
Stainless steel
-25 °C (-13 °F)
-40 °C (-40 °F)
5)
60 °C (140 °F) -25 °C (-13 °F) 180 °C (356 °F)
ETFE
3)
Steel -10 °C (14°F) 60 °C (140 °F) -10 °C (14°F) 130 °C (266 °F)
ETFE
3)
Stainless steel
-25 °C (-13 °F)
-40 °C (-40 °F)
5)
60 °C (140 °F) -25 °C (-13 °F) 130 °C (266 °F)
1) PFA (high-temperature version) can be obtained for nominal sizes ≥ DN 10
2) Thick PTFE can be obtained for nominal sizes ≥ DN 25
3) ETFE can be obtained for nominal sizes ≥ DN 25
4) Only China production site
5) For (optional) low-temperature version, only
