3 Maintenance
3.4.3. Oil change, gearbox axis 2
3HAC022033-001 Revision: K204
© Copyright 2004-2011 ABB. All rights reserved.
Draining, oil
The procedure below details how to drain the oil in gearbox axis 2.
When using the oil exchange equipment, follow the instructions enclosed with the kit. Art.
no. for the kit is specified in Required equipment on page 203.
Action Note
1.
DANGER!
Turn off all electric power, hydraulic and
pneumatic pressure supplies to the robot!
Turn off all electric power and hydraulic but
not the air pressure to the gearboxes, motors
and SMB.
2.
WARNING!
Handling gearbox oil involves several safety
risks. Before proceeding, please read the
safety information in the section WARNING -
Safety risks during work with gearbox
lubricants (oil or grease) on page 51.
3. Remove the oil plug, draining, and drain the
gearbox oil using a hose with nipple and an
oil collecting vessel.
Remove the oil plug, filling in order to drain
the oil quicker!
Shown in the figure Location of oil plugs
on page 203.
Vessel capacity is specified in Required
equipment on page 203.
NOTE!
Draining is time-consuming. Elapsed
time varies depending on the
temperature of the oil.
4. Refit the oil plug. Tightening torque: 24 Nm.
Continued
Continues on next page
