8 Spare part / part list
8.3.5. Base incl frame axis 1, 3HAC12304-1
3HAC022033-001 Revision: K442
© Copyright 2004-2011 ABB. All rights reserved.
8.3.5. Base incl frame axis 1, 3HAC12304-1
Part list
Base machining, 3HAC10044-1
Frame incl axis 1 gearbox, 3HAC12303-1
Item Qty Art. number Description Note
101.1 1 3HAC10044-1 Base, machining See section below.
101.2 1 3HAC12303-1 Frame incl ax 1 gearbox See section below.
101.3 3 3HAC11732-2 Washer T=3
101.4 18 3HAB7700-89 Hex socket head cap screw UNBRAKO 12.9
Gleitmo 610, M16x90
101.5 1 3HAC11529-1 Rubber lined clip D=28
101.6 1 3HAC14453-1 Hose with flange
101.7 1 3HAC14453-2 Plug
101.8 1 3HAC4428-2 Hose Clip
101.9 1 9ADA618-56 Torx pan head screw Steel 8.8-A2F, M6x16
Item Qty Art. number Description Note
101.1.1 1 3HAC10044-2 Base, casting
101.1.2 5 3HAC4836-7 Protection plug
101.1.3 1 3HAC1383-2 Protection Cover compl.
101.1.4 1 3HAC14024-1 Protection screw
Item Qty Art. number Description Note
101.2.1 1 3HAC15865-1 Frame machining
101.2.2 1 3HAC10828-1 RV 500C-219,95 assembly
101.2.3 24 3HAB7700-77 Hex socket head cap screw UNBRAKO 12.9
Gleitmo 610, M12x110
101.2.4 24 3HAA1001-134 Washer 13x19x1,5
