4 Repair
4.5.3. Replacement of balancing device
3073HAC022033-001 Revision: K
© Copyright 2004-2011 ABB. All rights reserved.
4.5.3. Replacement of balancing device
Location of balancing device
The balancing device is located on rear top of the frame as shown in the figure below.
xx0100000139
A Balancing device
B Rear cover
C Support shaft inside (included in balancing device 3HAC14675-1)
D Attachment screws, rear cover
E Balancing device shaft, including screw and washer
F Bearing attachment
G Parallel pin (inside bearing attachment)
H Attachment screws, bearing attachment
Continues on next page
