10 Circuit Diagram
10.2.1. Validity of circuit diagram 3HAC 025744-1
4713HAC022033-001 Revision: K
© Copyright 2004-2011 ABB. All rights reserved.
10.2 Circuit diagram 3HAC 025744-001
10.2.1. Validity of circuit diagram 3HAC 025744-1
Is this circuit diagram valid for your robot?
The validity of the circuit diagram depends on which cable harness is fitted to the robot.
Check the article number of the cable harness fitted to the robot and see page 3 of the circuit
diagram in order to determine if the diagram is valid for the harness or not.
Where to find the article number Action
Label on the cable harness The label is located at the connectors in the base.
Remove the rear cover plate to see the label.
