ABB M2000 - Inspection, Position Switch Axes 1, 2 and 3

3 Maintenance
3.3.12. Inspection, position switch axes 1, 2 and 3
1833HAC022033-001 Revision: K
© Copyright 2004-2011 ABB. All rights reserved.
3.3.12. Inspection, position switch axes 1, 2 and 3
Location of position switches
The position switches, axes 1, 2 and 3, are located as shown in the figures below.
xx0100000158
A Position switch, axis 1
B Cam
C Set screw, cam
D Protection sheet
E Rail
F Rail attachment
Continues on next page
