8 Spare part / part list

8.3.8. Axis 3-4, Foundry, 3HAC13063-4 (IRB 7600 -150/3.5, - 325/3.1, - 340/2.8, - 400/2.55, - 500/2.55)

4473HAC022033-001 Revision: K

8.3.8. Axis 3-4, Foundry, 3HAC13063-4 (IRB 7600 -150/3.5, - 325/3.1, - 340/2.8, - 400/

2.55, - 500/2.55)

Part list

Tube shaft 2,55 Foundry, 3HAC15932-1

Item Qty Art. no. Description Note

102.1 1 3HAC022181-001 Material set ax 4 See table Material set axis

4, 3HAC022181-001 on

page 443.

102.2 1 3HAC15932-1 Tube shaft 2,55

Foundry

See table below.

102.3 1 3HAC13062-1 Axis 3 See table Axis 3,

3HAC13062-1 on page

445.

Item Qty Art. number Description Note

102.2.1 1 3HAC10509-2 Tube shaft 2,55, cast

102.2.2 1 3HAC1383-2 Protection Cover compl.
