8.3.15. Arm extension set, 250 mm, 3HAC12311-2 (IRB 7600 - 340/2,8)
4613HAC022033-001 Revision: K
© Copyright 2004-2011 ABB. All rights reserved.
8.3.15. Arm extension set, 250 mm, 3HAC12311-2 (IRB 7600 - 340/2,8)
Part list
Item Qty Art. number Description Dimension
111.501 1 3HAC9760-1 Arm extender 250 mm
111.501 1 3HAC15932-3 Arm extender 250 mm Foundry
111.502 1 3HAC11755-1 Friction washer
111.503 20 3HAB7700-69 Hex socket head cap screw M12x50
111.504 20 3HAA1001-134 Washer 13x19x1.5
111.505 1 9ABA107-56 Parallel pin 10x20
