4 Repair
4.6.4. Replacement of motor, axis 4
3493HAC022033-001 Revision: K
© Copyright 2004-2011 ABB. All rights reserved.
Removal, motor axis 4
The procedure below details how to remove the motor, axis 4.
Lifting tool, motor ax
1, 4, 5
3HAC14459-1 To be used if the upper arm is
positioned vertically.
Lifting tool, motor ax
2, 3, 4
3HAC15534-1 To be used if the upper arm is
positioned horizontally.
Removal tool, motor
M12x
3HAC14973-1 Always use the removal tools
in pairs!
Guide pins M10 x
100
3HAC15521-1 For guiding the motor.
Guide pins M10 x
150
3HAC15521-2 For guiding the motor.
Extension 300mm
for bits 1/2"
3HAC12342-1
Rotation tool 3HAC17105-1 Used to rotate the motor
pinion when mating it to the
gear when brakes are
released with 24 VDC power
supply.
Power supply - 24 VDC, max. 1,5 A
For releasing the brakes.
Standard toolkit - Content is defined in section
Standard toolkit on page 427.
Calibration
Pendulum toolkit
3HAC15716-1 Complete kit that also
includes operating manual.
Other tools and
procedures may be
required. See
references to these
procedures in the
step-by-step
instructions below.
These procedures include
references to the tools
required.
Circuit Diagram See chapter Circuit diagram.
Equipment, etc. Spare part no. Art. no. Note
Action Note
1. Move the upper arm to one of the basic
positions:
• upper arm is pointed straight up. This
position enables the motor to be
replaced without draining the gear
oil, which in turn saves time.
• upper arm is close to horizontal. This
position is recommended if the
gearbox is also to be replaced, i.e.
when the gearbox oil has to be
drained anyway.
Continued
Continues on next page
