1 Safety
1.3.6. WARNING - The unit is sensitive to ESD!
3HAC022033-001 Revision: K50
© Copyright 2004-2011 ABB. All rights reserved.
Assemble the wrist strap
The picture illustrates how the ESD wrist strap is assembled in the controller.
xx0400001055
A The strap is fastened to a button on the side of the control module.
B When not used, the wrist strap is placed on the power supply unit.
C Power supply unit
Continued
