ScreenMaster RVG200
Paperless recorder 8 Specification
138 OI/RVG200-EN
Operator views Standard functionality
Operator messages
Secure chart signatures
Recorded in the alarm / event log,
complete with operator identification
Process alarms
Real-time alarms
Custom linearization
Views available
Contents Chart Bargraph Digital
indicator
Instantaneous
values / states
Units of measure
Channel tags
Alarm status
Alarm trip markers —
Max. / Min. markers —
Analog bargraphs —
Totalizer values & units
of measure
—— *
Totalizer tags — — *
Maximum, minimum
and average batch
values
—— *
Graphical view of
historical data
——
* If Totalizer option is fitted and selected
Number: 24
Trigger: Via front panel or digital signals
Recording in
alarm / event log:
Can be enabled or disabled on
configuration
Number: 96 (4 per recording channel)
Types:
High / low: Process
Latch
Annunciator
Rate: Fast / slow
Tag: 20-character tag for each alarm
Hysteresis: Programmable value and time
hysteresis (1 to 9999 seconds)
Alarm enable: Allows alarm to be enabled /
disabled via a digital input
Alarm log enable: Recording of alarm state
changes in the alarm / event log
can be enabled / disabled for
each alarm
Acknowledgement: Via front panel or digital signals
Number: 4
Programmable: Day of the week, 1
st
of month,
start and duration times
Number: 2
Number of
breakpoints:
20 per linearizer
