ScreenMaster RVG200
Paperless recorder 7 Configuration
OI/RVG200-EN 79
7.7.7 Operator messages
Op. Messages 1..6 (and 7 to 24)
Message 1 (to 6) Operator messages can be triggered via the Operator menus or a digital
signal. The message is stored in the Alarm Event log and may also be
annotated on the chart view.
Message tag Enter the message text – 20 characters maximum.
Refer to Appendix F, page 180 for further information regarding character
use in tags.
Source ID Select a signal source used to trigger the operator message. Refer to
Appendix A, page 146 for a description of the available sources.
Note. This signal is edge-triggered. A rising edge (inactive to active) or a
falling edge (active to inactive) triggers the addition of the operator
message to the Alarm Event log.
Assign to group Select the group(s) to which the message is to apply.
