ABB ScreenMaster RVG200 - Communications - Analog and Digital Inputs

ScreenMaster RVG200
Paperless recorder Appendix B – MODBUS TCP / MODBUS 485
164 OI/RVG200-EN
B.6 Communications – analog and digital inputs
Comms.
digital
inputs
Comms.
analog input
failure
Comms.
analog inputs
Comms.
digital
inputs
Comms.
analog input
failure
Comms.
analog inputs
0 = Inactive
1 = Active
IEEE floating
point
0 = Inactive
1 = Active
IEEE floating
point
Input
number
MODBUS
coil
MODBUS
coil
MODBUS
register
Input
number
MODBUS
coil
MODBUS
coil
MODBUS
register
1 1001 1051 5001 and 5002 13 1013 1063 5025 and 5026
2 1002 1052 5003 and 5004 14 1014 1064 5027 and 5028
3 1003 1053 5005 and 5006 15 1015 1065 5029 and 5030
4 1004 1054 5007 and 5008 16 1016 1066 5031 and 5032
5 1005 1055 5009 and 5010 17 1017 1067 5033 and 5034
6 1006 1056 5011 and 5012 18 1018 1068 5035 and 5036
7 1007 1057 5013 and 5014 19 1019 1069 5037 and 5038
8 1008 1058 5015 and 5016 20 1020 1070 5039 and 5040
9 1009 1059 5017 and 5018 21 1021 1071 5041 and 5042
10 1010 1060 5019 and 5020 22 1022 1072 5043 and 5044
11 1011 1061 5021 and 5022 23 1023 1073 5045 and 5046
12 1012 1062 5023 and 5024 24 1024 1074 5047 and 5048
Table B.16 MODBUS inputs
