ScreenMaster RVG200
Paperless recorder 6 Archiving
56 OI/RVG200-EN
6.4 Archive filenames
Examples of archive filenames are shown in Table 6.2.
6.5 Channel data file creation
A new channel data file is created under the following conditions:
 When the current file for a channel does not exist on the media card.
 When the maximum size (6 MB) of the existing data file is exceeded.
6.6 Log file creation
A new log file is created under the following conditions:
 When an existing valid log file does not exist on the media card.
 When the maximum size (6 MB) of the existing log file is exceeded.
Type Format
Analog
channel data
files
<Start Date>_<Start Time>_<Serial Number>_Ch<Group>_<Channel>_Analogue000
For example, 20130516_160838_3K10000123456_CH1_02_Analogue0000.DXO
Digital
channel data
files
<Start Date>_<Start Time>_<Serial Number>_Ch<Group>_<Channel>_Analogue000
For example, 20130516_160838_3K10000123456_CH1_02_Digital0000.DXO
Alarm Event
log files
<Start Date>_<Start Time>_<Serial Number>_alarm
For example, 20130516_160838_3K10000123456_alarm.EXO
Totalizer log
files
<Start Date>_<Start Time>_<Serial Number>_totalizer
For example, 20130516_160838_3K10000123456_totalizer.TXO
Audit log
files
<Start Date>_<Start Time>_<Serial Number>_audit
For example, 20130516_160838_3K10000123456_audit.AXO
Batch log
files
<Start Date>_<Start Time>_<Serial Number>_batch
For example, 20130516_160838_3K10000123456_batch.EXO
Table 6.2 Archive filenames
