ScreenMaster RVG200
Paperless recorder Appendix B – MODBUS TCP / MODBUS 485
152 OI/RVG200-EN
4A 113 212 16A 161 261
4B 114 213 16B 162 262
4C 115 214 16C 163 263
4D 116 215 16D 164 264
5A 117 216 17A 165 265
5B 118 217 17B 166 266
5C 119 218 17C 167 267
5D 120 219 17D 168 268
6A 121 220 18A 169 269
6B 122 221 18B 170 270
6C 123 222 18C 171 271
6D 124 223 18D 172 272
7A 125 225 19A 173 273
7B 126 226 19B 174 274
7C 127 227 19C 175 275
7D 128 228 19D 176 276
8A 129 229 20A 177 277
8B 130 230 20B 178 278
8C 131 231 20C 179 279
8D 132 232 20D 180 280
9A 133 233 21A 181 281
9B 134 234 21B 182 282
9C 135 235 21C 183 283
9D 136 236 21D 184 284
10A 137 237 22A 185 285
10B 138 238 22B 186 286
10C 139 239 22C 187 287
10D 140 240 22D 188 288
11A 141 241 23A 189 289
11B 142 242 23B 190 290
11C 143 243 23C 191 291
11D 144 244 23D 192 292
Active / Inactive
state
Acknowledge state
Active / Inactive
state
Acknowledge state
Read
access
0 = Inactive
1 = Active
0 = Acknowledged or
inactive
1 = Active and
unacknowledged
Read
access
0 = Inactive
1 = Active
0 = Acknowledged or
inactive
1 = Active and
unacknowledged
Write
access
None
0 = No effect
1 = Acknowledge
Write
access
None
0 = No effect
1 = Acknowledge
Alarm MODBUS coil MODBUS coil Alarm MODBUS coil MODBUS coil
Table B.3 Alarm states (Continued)
