ScreenMaster RVG200
Paperless recorder Appendix B – MODBUS TCP / MODBUS 485
154 OI/RVG200-EN
Read only: 0 = Alarm group inactive
1 = Alarm group active
Read only: 0 = Alarm group inactive
1 = Alarm group active
Alarm group MODBUS coil Alarm group MODBUS coil
Alarm group 1 301 Alarm group 7 307
Alarm group 2 302 Alarm group 8 308
Alarm group 3 303 Alarm group 9 309
Alarm group 4 304 Alarm group 10 310
Alarm group 5 305 Alarm group 11 311
Alarm group 6 306 Alarm group 12 312
Table B.4 Alarm groups
Read only: 0 = All alarms inactive
1 = At least 1 alarm active
Title MODBUS coil
Any alarm 325
Table B.5 Any alarm
Read only: 0 = Alarm inactive
1 = Alarm active
Read only: 0 = Alarm inactive
1 = Alarm active
Real-time alarm MODBUS coil Real-time alarm MODBUS coil
Real-time alarm 1 331 Real-time alarm 3 333
Real-time alarm 2 332 Real-time alarm 4 334
Table B.6 Real-time alarms
Read: Always returns '0'
Write: 1 = Activate
Read: Always returns '0'
Write: 1 = Activate
Operator message MODBUS coil Operator message MODBUS coil
Operator Message 1 350 Operator Message 13 362
Operator Message 2 351 Operator Message 14 363
Operator Message 3 352 Operator Message 15 365
Operator Message 4 353 Operator Message 16 366
Operator Message 5 354 Operator Message 17 367
Operator Message 6 355 Operator Message 18 368
Operator Message 7 356 Operator Message 19 369
Operator Message 8 357 Operator Message 20 370
Operator Message 9 358 Operator Message 21 371
Operator Message 10 359 Operator Message 22 372
Operator Message 11 360 Operator Message 23 373
Operator Message 12 361 Operator Message 24 374
Table B.7 Operator messages
