ScreenMaster RVG200
Paperless recorder Appendix B – MODBUS TCP / MODBUS 485
156 OI/RVG200-EN
MODBUS registers
Stop / Go Reset Wrap pulse 1st stage pulse Flowrate failure
Read access 0 = Stopped
1 = Running
0 = >1s*
1 = <1s*
0 = Inactive
1 = Active
0 = Inactive
1 = Active
0 = Inactive
1 = Active
Write access 0 = Stop
1 = Start
1 = Reset
Totalizer MODBUS coil MODBUS coil MODBUS coil MODBUS coil MODBUS coil
1A 401 501 601 701 801
1B 402 502 602 702 802
2A 403 503 603 703 803
2B 404 504 604 704 804
3A 405 505 605 705 805
3B 406 506 606 706 806
4A 407 507 607 707 807
4B 408 508 608 708 808
5A 409 509 609 709 809
5B 410 510 610 710 810
6A 411 511 611 711 811
6B 412 512 612 712 812
7A 413 513 613 713 813
7B 414 514 614 714 814
8A 415 515 615 715 815
8B 416 516 616 716 816
9A 417 517 617 717 817
9B 418 518 618 718 818
10A 419 519 619 719 819
10B 420 520 620 720 820
11A 421 521 621 721 821
11B 422 522 622 722 822
12A 423 523 623 723 823
12B 424 524 624 724 824
13A 425 525 625 725 825
13B 426 526 626 726 826
14A 427 527 627 727 827
14B 428 528 628 728 828
15A 429 529 629 729 829
15B 430 530 630 730 830
16A 431 531 631 731 831
16B 432 532 632 732 832
17A 433 533 633 733 833
17B 434 534 634 734 834
Table B.9 Totalizer digital signals
