ScreenMaster RVG200
Paperless recorder Appendix B – MODBUS TCP / MODBUS 485
158 OI/RVG200-EN
Channel number / MODBUS coil
Signal 1 2 3 4 5 6 7 8 9 10 11 12
Channel Fail
Status
Read only 1101 1201 1301 1401 1501 1601 1701 1801 1901 2001 2101 2201
Alarm A Read only 1102 1202 1302 1402 1502 1602 1702 1802 1902 2002 2102 2202
Alarm B Read only 1103 1203 1303 1403 1503 1603 1703 1803 1903 2003 2103 2203
Alarm C Read only 1104 1204 1304 1404 1504 1604 1704 1804 1904 2004 2104 2204
Alarm D Read only 1105 1205 1305 1405 1505 1605 1705 1805 1905 2005 2105 2205
Alarm A
Acknowledge
Read / Write 1106 1206 1306 1406 1506 1606 1706 1806 1906 2006 2106 2206
Alarm B
Acknowledge
Read / Write 1107 1207 1307 1407 1507 1607 1707 1807 1907 2007 2107 2207
Alarm C
Acknowledge
Read / Write 1108 1208 1308 1408 1508 1608 1708 1808 1908 2008 2108 2208
Alarm D
Acknowledge
Read / Write 1109 1209 1309 1409 1509 1609 1709 1809 1909 2009 2109 2209
Totalizer A
Stop/Go
Read / Write 1110 1210 1310 1410 1510 1610 1710 1810 1910 2010 2110 2210
Totalizer A Reset Read / Write 1111 1211 1311 1411 1511 1611 1711 1811 1911 2011 2111 2211
Totalizer A Wrap Read only 1112 1212 1312 1412 1512 1612 1712 1812 1912 2012 2112 2212
Totalizer A First
Stage
Read only 1113 1213 1313 1413 1513 1613 1713 1813 1913 2013 2113 2213
Totalizer A
Flowrate Fail
Read only 1114 1214 1314 1414 1514 1614 1714 1814 1914 2014 2114 2214
Totalizer B
Stop/Go
Read / Write 1115 1215 1315 1415 1515 1615 1715 1815 1915 2015 2115 2215
Totalizer B Reset Read / Write 1116 1216 1316 1416 1516 1616 1716 1816 1916 2016 2116 2216
Totalizer B Wrap Read only 1117 1217 1317 1417 1517 1617 1717 1817 1917 2017 2117 2217
Totalizer B First
Stage
Read only 1118 1218 1318 1418 1518 1618 1718 1818 1918 2018 2118 2218
Totalizer B
Flowrate Fail
Read only 1119 1219 1319 1419 1519 1619 1719 1819 1919 2019 2119 2219
Channel Type Read only 1120 1220 1320 1420 1520 1620 1720 1820 1920 2020 2120 2220
Digital Value Read only 1121 1221 1321 1421 1521 1621 1721 1821 1921 2021 2121 2221
Table B.10 Channel digital signals (channels 1 to 12)
