Abbott FreeStyle Precision Pro - Page 176

12-4
Questions? Refer to Page 11-22 For Technical Support Instructions.
Replacement
1. Obtain a replacement strip port module.
2. Slide the replacement strip port module into position on the meter. (Fig. 3)
3. Insert strip port module rmly into place. (Fig.4)
4. Use a small cross head (Phillips) screwdriver to insert the new screw. is will
secure the strip port module in place. (Fig. 5)
Figure 3
Figure 4
Figure 5
Chapter 12: Maintenance
